Product details
Expressive Arranger Sound. Intuitive Control. A New PSR-SX Starting Point.
The Yamaha PSR-SX620 opens the door to the PSR-SX arranger workstation range for intermediate players, aspiring performers and musicians developing their arranging skills. Its 61-note touch-sensitive keyboard, redesigned control panel and 4.3-inch colour display keep essential functions close at hand in a compact 8.1 kg instrument.
With 1,002 preset Voices, 450 accompaniment Styles, 137 Super Articulation Voices, Chord Looper, a joystick, two assignable Live Control knobs, Bluetooth audio and USB audio recording, PSR-SX620 provides a flexible platform for practice, performance, songwriting and creative exploration.
Key Features
61-note touch-sensitive keyboard with hands-on expression
The organ-style keyboard responds to your playing dynamics and offers five selectable touch curves. A joystick provides pitch and modulation control, while two assignable Live Control knobs let you shape tone, effects and Style parameters in real time.
More than 1,000 Voices with Super Articulation realism
Choose from 1,002 preset Voices, 51 Drum/SFX Kits and 480 XG Voices. The collection includes 137 Super Articulation Voices that recreate characteristic instrumental details, supported by 128-note polyphony and a comprehensive effects system.
450 accompaniment Styles with Chord Looper
The library includes 416 Pro, 33 Session and 1 Free Play Style, each with four One Touch Settings. Chord Looper records and repeats chord progressions—with up to eight sequences per bank—freeing your left hand for melody, improvisation or live sound control.
Redesigned panel with a clear 4.3-inch colour display
The 480 × 272 colour display and refreshed panel layout make it easy to navigate Voices, Styles, songs and registrations. Dedicated controls keep frequently used arranger functions accessible without interrupting the flow of a performance.
Microphone input, Bluetooth audio and flexible recording
Connect a microphone and shape the input with noise gate, compressor and three-band EQ. Record 16-track MIDI arrangements or capture stereo WAV audio to a USB flash drive, while Bluetooth audio lets you stream songs wirelessly for practice and play-along sessions.
Refined 30-watt speaker system in a compact cabinet
Two 15 W amplifier channels drive a pair of 12 cm speakers. Yamaha's Internal BassPort, enlarged sound chamber and front-facing bass-reflex design help deliver deeper, cleaner low-frequency response, while upgraded line outputs provide a clear signal for external amplification.
FAQ
Q. Who is the PSR-SX620 best suited to?
It is designed for intermediate players, aspiring performers, keyboard-exam students, songwriters and home musicians who want to enter the PSR-SX range with expressive sounds and practical arranger tools.
Q. What is the main difference between PSR-SX620 and PSR-SX720+?
PSR-SX620 offers the core arranger experience with 1,002 Voices, 450 Styles, Chord Looper, joystick control and Bluetooth audio in a lighter 8.1 kg body. PSR-SX720+ adds the 61-note FSB action, a 7-inch touchscreen, larger Voice library, Style Dynamics Control, more internal and expansion memory, additional controls and broader audio recording support.
Q. Is the 4.3-inch display a touchscreen?
No. PSR-SX620 uses a 4.3-inch colour LCD with physical panel controls. The larger 7-inch touch interface is available on PSR-SX720+ and PSR-SX920.
Q. Does it have built-in speakers?
Yes. Its newly developed system provides 15 W × 2 amplification through two 12 cm speakers, with an Internal BassPort for stronger low-frequency response and main line outputs for a mixer, amplifier or PA.
Q. Can I connect a microphone?
Yes. A dedicated microphone input is provided, together with noise gate, compressor and three-band EQ processing. PSR-SX620 does not include the Vocal Harmony and Synth Vocoder functions found on PSR-SX920.
Q. Can I record songs and audio?
Yes. It supports 16-track MIDI song recording and stereo WAV audio recording and playback through a USB flash drive. Audio tools include time stretch, pitch shift and vocal cancel.
Q. Can I add expansion Voices and Styles?
Yes. PSR-SX620 provides approximately 380 MB for Expansion Voices and supports Expansion Styles through internal memory. Yamaha's Expansion Explorer app helps you discover and manage compatible content.
Q. What is included in the box?
Yamaha lists the owner's manual, music rest and AC adaptor; included items may vary by region.
Why Buy from YMS?
- ✓ Authorised Yamaha Premium Retailer: Buy a genuine India-market Yamaha instrument with official manufacturer warranty support.
- ✓ Arranger-workstation guidance: Our team can help with Styles, registrations, microphone setup, amplification, pedals and performance workflows.
- ✓ Support beyond the keyboard: Ask us about suitable stands, benches, pedals, headphones, cases, microphones and cables.
- ✓ Pan-India delivery: Order from anywhere in India, subject to serviceability for your location.
- ✓ Physical-store support: YMS teams in Bengaluru and Mangaluru are available for product enquiries and after-sales guidance.
Specifications
Overview
| Model | Yamaha PSR-SX620 |
|---|---|
| Instrument type | Digital arranger workstation |
| Keyboard | 61-note organ-style keyboard with initial touch |
| Touch response | Normal; Soft 1; Soft 2; Hard 1; Hard 2 |
| Display | 4.3-inch TFT colour WQVGA LCD (480 × 272); non-touch |
| Controllers | Joystick; 2 assignable Live Control knobs |
Dimensions and weight
| Width | 993 mm (39-1/8 in) |
|---|---|
| Height | 143 mm (5-5/8 in) |
| Depth | 404 mm (15-7/8 in) |
| Weight | 8.1 kg (17 lb, 14 oz) |
Voices and effects
| Tone generation | AWM Stereo Sampling |
|---|---|
| Maximum polyphony | 128 notes |
| Preset Voices | 1,002 Voices + 51 Drum/SFX Kits + 480 XG Voices |
| Featured Voices | 137 S.Articulation; 34 MegaVoice; 31 Sweet!; 74 Cool!; 89 Live! |
| Expansion Voice memory | Approx. 380 MB |
| Keyboard Parts | Right 1; Right 2; Left |
| Reverb | 59 preset + 30 user |
| Chorus | 106 preset + 30 user |
| DSP | 322 preset + 30 user |
| Insertion effect blocks | 9 blocks |
| Microphone effects | Noise Gate; Compressor; 3-band EQ |
Accompaniment Styles
| Preset Styles | 450 |
|---|---|
| Featured Styles | 416 Pro; 33 Session; 1 Free Play |
| Style controls | 3 Intros; 4 Main Variations; 4 Fills; Break; 3 Endings |
| One Touch Setting | 4 for each Style |
| Chord Looper | Yes |
| Style compatibility | SFF and SFF GE |
| Expansion Styles | Yes, using internal memory |
Songs, recording and performance
| MIDI recording | 16 tracks; Quick Recording and Multi Track Recording |
|---|---|
| MIDI formats | Playback: SMF 0/1 and XF; Recording: SMF 0 |
| Audio recording | WAV 44.1 kHz/16-bit stereo to USB flash drive |
| Maximum audio recording time | 80 minutes per Song |
| Audio playback tools | Time Stretch; Pitch Shift; Vocal Cancel |
| Registration Memory | 8 buttons; Registration Sequence and Freeze |
| Playlist | Up to 500 records per Playlist file |
| Tempo range | 5-500 BPM; Tap Tempo |
Storage and connectivity
| Internal memory | Approx. 20 MB maximum |
|---|---|
| External storage | USB flash drive |
| Microphone input | Yes |
| Headphones | 6.3 mm stereo phone jack |
| Aux input | 3.5 mm stereo mini jack |
| Line outputs | Main L/L+R and R |
| Foot pedals | 2 assignable pedal connections |
| USB | USB TO DEVICE; USB TO HOST |
| Bluetooth audio | Yes |
Amplification, power and accessories
| Amplifiers | 15 W × 2 |
|---|---|
| Speakers | 2 × 12 cm |
| Power supply | Yamaha PA-300C or equivalent recommended adaptor |
| Power consumption | 18 W |
| Auto power off | Yes |
| Included accessories | Owner's Manual; Online Member Product Registration; music rest; AC adaptor (regional inclusion may vary) |
Specifications are based on Yamaha India's published PSR-SX620 specifications and may change with firmware updates or vary by region.
