Yamaha MODX M6 61-Key Music Synthesizer

Three synth engines in a 6.6 kg, 61-key body

61-note semi-weighted FSB keyboard with initial touch
AWM2, FM-X and AN-X engines with 268-note total polyphony
Lightest MODX M at 6.6 kg, easy to carry to every gig
Motion Control, Super Knob and 7-inch colour touchscreen
USB MIDI 2.0 with 10-out/4-in audio and DAW Remote control

MRP~~₹1,46,990~~10% OFF

YMS Price₹1,32,291

Taxes included.

Required accessory

MRP~~₹6,890~~10% OFF

YMS Price₹6,201

One adaptor per instrument is added to your cart and charged separately.

Yamaha MODX M6 61-Key Synthesizer with AWM2, FM-X and AN-X Engines

The Yamaha MODX M6 is a 61-key music synthesizer that shares its sound architecture with Yamaha's flagship MONTAGE M. It combines AWM2 sampling, FM-X and AN-X analogue-style synthesis under Motion Control, with 3,487 preset Performances and a 7-inch colour touchscreen. It suits synth players, gigging keyboardists and producers who want deep sound design without a heavy rig. At 6.6 kg it is the most portable MODX M, and its USB audio interface and DAW Remote make it just as useful on a studio desk.

Key Features

Musician playing the Yamaha MODX M6 61-key synthesizer

Yamaha MODX M6: 61 semi-weighted keys at 6.6 kg

The MODX M6 uses a 61-note semi-weighted FSB keyboard with initial touch, quick enough for synth leads, organ runs and rhythmic parts. At 6.6 kg and 882 mm wide, it is the lightest and most compact model in the series, easy to carry to rehearsals and to fit into a small studio desk.

AWM2, FM-X and AN-X polyphony of the Yamaha MODX M6

Three engines: AWM2, FM-X and AN-X

The MODX M6 pairs AWM2 sample-based synthesis, with up to 128 Elements per Part for detailed pianos and strings, with 8-operator FM-X and the analogue-modelling AN-X engine. Polyphony totals 268 notes: 128 for AWM2, 128 for FM-X and 12 for AN-X, so dense layers and splits stay clear.

AN-X engine edit screen on the Yamaha MODX M6

AN-X engine for vintage analogue character

AN-X gives you two filters with 10 filter types, pulse width modulation, oscillator self sync, ring modulation, FM, a wave shaper and a wave folder. Voltage drift and ageing settings imitate the slight instability of classic synths, adding warmth and movement to leads, basses and pads.

Motion Control Synthesis Engine diagram for the Yamaha MODX M6

Motion Control, Super Knob and high-resolution controls

Motion Sequences animate synth and effect parameters in time with the tempo, the Super Knob sweeps many settings with a single turn, and the Envelope Follower lets audio from the A/D input or another Part shape a sound. The knobs, Super Knob, pitch bend and modulation wheels are high resolution for smoother changes.

Yamaha MODX M6 control panel and display viewed from the front left

Dedicated Part and Scene buttons for live control

Dedicated Part and Scene buttons give direct access to 8 Parts per Performance, backed by 8 sliders, 4 knobs and 4 pedal inputs. Switching sounds and reshaping a mix mid-song stays quick, which matters on a crowded stage.

Editing on the touchscreen of the Yamaha MODX M6

Touchscreen editing and stereo A/D input

A 7-inch colour touchscreen with six display knobs speeds up browsing and editing. The stereo A/D input, with two insertion effects of its own, lets you route an external instrument or audio source into a Performance and process it alongside the internal sounds.

USB MIDI 2.0 and 10-out/4-in audio interface of the Yamaha MODX M6

MODX M6 as a USB MIDI 2.0 audio interface and DAW controller

A single USB cable handles MIDI 2.0 data and multichannel audio, with 10 outputs and 4 inputs at 44.1 kHz. The dedicated DAW Remote button turns the panel into a controller for Cubase, Logic, Pro Tools and Live, and Cubase AI download information is included to get you recording.

Expanded Softsynth Plugin for the Yamaha MODX M6 running in a DAW

Expanded Softsynth Plugin for your DAW

Registered MODX M owners get the Expanded Softsynth Plugin free of charge. It recreates the instrument inside your DAW, so you can build, edit and mix Performances for your MODX M6 even when the hardware is not with you.

Watch & Hear It

Frequently Asked Questions

How does the MODX M6 compare with the MONTAGE M6?

Both use 61 keys and the same AWM2, FM-X and AN-X engines with 3,487 Performances. The MONTAGE M6 adds an FSX keyboard with channel aftertouch, higher polyphony (256 AWM2 and 16 AN-X notes) and 3.7 GiB of user wave memory, but weighs 15.3 kg. The MODX M6 is far lighter at 6.6 kg, with a semi-weighted FSB keyboard and no aftertouch.

Should I choose the MODX M6 or the CK61 stage keyboard?

The CK61 is a simpler stage keyboard with built-in speakers, battery operation and 363 Voices, which makes it handy for quick setups. The MODX M6 is a full synthesizer with three synthesis engines, deep editing, a sequencer and a multichannel USB audio interface, so it is the better pick for sound design and production.

Is the MODX M6 keyboard weighted, and does it have aftertouch?

It uses a 61-note semi-weighted FSB keyboard with initial touch (velocity response) but no aftertouch. If you want weighted, graded-hammer keys for piano playing, the 88-key MODX M8 is the model to look at.

Can I record into a computer with the MODX M6?

Yes. Over one USB cable it works as a MIDI 2.0 controller and an audio interface with 4 inputs and 10 outputs at 44.1 kHz, or 2 in/2 out at 44.1, 48 or 96 kHz. Cubase AI download information is included, and the DAW Remote button controls Cubase, Logic, Pro Tools and Live.

What comes in the box with the MODX M6, and how is it powered?

Yamaha lists the PA-300C AC adaptor, a Quick Guide, Cubase AI download information, Expanded Softsynth Plugin for MONTAGE M/MODX M download information, manual download information and a welcome card. The MODX M6 runs from the PA-300C adaptor and draws 19 W.

Can I load my own samples into the MODX M6?

Yes. The MODX M6 has 1.9 GB of user wave memory for your own waveforms, alongside 11.29 GB of preset wave (when converted to 16-bit linear format).

Why Buy from YMS?

Authorised Yamaha Premium Retailer
Genuine stock with full manufacturer warranty
Demo units at our Bengaluru and Mangaluru stores
Secure delivery across India
Free domestic shipping on all orders

Specifications

Overview

Model	Yamaha MODX M6
Instrument type	Music synthesizer
Keyboard	61-note semi-weighted FSB keyboard
Initial touch	Yes
Aftertouch	No

Dimensions and weight

Width	882 mm (34-3/4 in)
Height	117 mm (4-5/8 in)
Depth	347 mm (13-11/16 in)
Weight	6.6 kg (14 lb, 9 oz)

Sound engines and polyphony

Synthesis engine	Motion Control Synthesis Engine
AWM2	Up to 128 Elements
FM-X	8 Operators; 88 Algorithms
AN-X	3 Oscillators; 1 Noise source
Maximum polyphony	AWM2: 128; FM-X: 128; AN-X: 12
Multitimbral capacity	16 internal Parts; stereo A/D and USB audio input Parts
Filters	18 types
Effects	13 Reverb; 91 Variation; 91 Insertion A; 94 Insertion B; 28 Master Effect types; Master EQ and Part EQ

Sound memory and performance

Preset waveform memory	11.29 GB (converted to 16-bit linear format)
User waveform memory	1.9 GB
Performances	3,487
Live Sets	Preset: 256; User: 2,048
Arpeggios	Up to 8 Parts simultaneously; 10,922+ preset; 256 user

Recorder and sequencer

Note capacity	Approx. 130,000 notes per Song/Pattern; approx. 520,000-note storage each for Songs and Patterns
Resolution	480 ppq
Tempo range	5–300 BPM
Sequence formats	MONTAGE M/MODX M original format; SMF formats 0 and 1
Patterns	128; 16 sequence tracks
Songs	128; 16 sequence tracks plus Tempo and Scene tracks
Recording modes	Real-time replace and overdub; Songs also support punch in/out

Controls, display and connectivity

Display	7-inch TFT colour Wide VGA LCD touchscreen
Controllers	Master Volume; A/D Input Gain; Pitch Bend and Modulation wheels; 8 sliders; 4 knobs; Super Knob; 6 display knobs; Portamento knob; Data Dial; 2 assignable switches; MSEQ Trigger; Portamento; Keyboard Hold
USB audio interface	44.1 kHz: 4 inputs / 10 outputs; 44.1, 48 or 96 kHz: 2 inputs / 2 outputs
USB	USB TO DEVICE; USB TO HOST
MIDI	MIDI IN and OUT
Foot control	2 Foot Controller inputs; Sustain and Assignable Foot Switch inputs
Audio outputs	L/MONO and R 6.3 mm outputs; 6.3 mm stereo headphone output
Audio inputs	A/D Input L/MONO and R, 6.3 mm

Power and included accessories

Power consumption	19 W with PA-300C AC adaptor
Included adaptor	Yamaha PA-300C
Other included items	Quick Guide; Cubase AI download information; Expanded Softsynth Plugin download information; manual-download information; welcome card
Built-in speakers	No

Specifications are based on Yamaha’s published MODX M specifications for OS v3.0 and may change with firmware updates or vary by region.
