Product details
Professional Stage Sound Wherever Inspiration Takes You
The Yamaha CK61 places expressive piano, electric piano, organ and synthesizer sounds in a lightweight 61-key stage keyboard built for immediate creativity. Its direct front-panel workflow, three-part architecture, built-in speakers, battery operation and comprehensive audio connectivity make it equally capable on stage, in rehearsal, at home or on the move.
A Complete Performance Palette
Authentic Yamaha Keyboard Sounds
Play voices inspired by the Yamaha CFX, S700 and CF3 concert grands, the characterful U1 upright, vintage reed and tine electric pianos, Clavi sounds, strings, brass and modern synth textures.
Dedicated Organ Control
Five organ types, nine physical drawbars, rotary-speaker control, percussion and enhanced vibrato/chorus provide a fast, musical organ workflow without menu diving.
Three Independent Parts
Split, layer and process three internal parts directly from the panel—combining bass, piano, organ, synths, pads or orchestral sounds into performance-ready setups.
Hands-On Sound Shaping
Dedicated filter and envelope controls, Mono and Unison modes, Drive, dual insertion effects, master delay, reverb and three-band EQ make real-time editing immediate.
FSB 61-Key Action
The responsive FSB keyboard offers increased key travel and stable resistance, giving organ, synth, piano and electric-piano parts an expressive, versatile playing feel.
Built for Live Control
Live Sets recall complete panel configurations, while four-zone MIDI Master functionality integrates external instruments, software and complex performance rigs.
Stage, Studio and Mobile Creativity
At only 5.6 kg, the CK61 is exceptionally portable. Its switchable stereo speakers support practice, writing and intimate performance without external amplification, while eight AA batteries can provide up to 4.5 hours with rechargeable Ni-MH cells or up to 3 hours with alkaline batteries. Battery life varies with use; batteries are not included.
Connected for Modern Performance
- Stereo A/D inputs with dedicated effects for a microphone, instrument or external source
- Two-channel USB audio and MIDI interface for recording and playback with a computer or compatible mobile device
- Bluetooth audio input for wireless backing tracks where supported in the market
- Traditional 5-pin MIDI In/Out, USB host/device connections and two foot-pedal inputs
- Stereo line outputs and a dedicated headphone connection
Frequently Asked Questions
Is the CK61 a synthesizer or a stage piano?
It combines elements of both. The CK61 is a stage keyboard with high-quality piano, electric piano and organ sounds, plus a broad synth palette and hands-on filter, envelope, effects and performance controls.
How is the CK61 different from the CK88?
The CK61 uses a compact 61-key FSB action suited to organ, synth and mixed keyboard work, and weighs 5.6 kg. The CK88 uses an 88-key Graded Hammer Standard action for a more piano-focused playing experience.
Can it operate without external speakers?
Yes. The CK61 includes switchable stereo speakers powered by two 6 W amplifiers, making it convenient for practice, rehearsals and small-scale playing.
Can I connect a microphone or another instrument?
Yes. Stereo A/D inputs accept an external audio source and provide two dedicated effects. That input can also be included in audio sent through the built-in USB interface.
Does it work as a MIDI controller?
Yes. Four-zone MIDI Master functionality, 5-pin MIDI In/Out and USB MIDI make the CK61 suitable for controlling external hardware and software instruments.
Is an AC adaptor included?
Yamaha specifies the PA-150B or an approved equivalent. Inclusion can vary by market and shipment, so please confirm the supplied accessories with YMS before purchase.
Why Buy from YMS?
Choose YMS for genuine Yamaha instruments, informed product guidance and dependable after-sales support. Our team can help compare key actions, accessories, amplification and performance connectivity so the CK61 fits your playing style and setup.
Specifications
Keyboard and sound engine
| Model | Yamaha CK61 |
|---|---|
| Keyboard | 61-key FSB keyboard with initial touch |
| Tone generation | AWM2 and AWM Organ Flutes |
| Maximum polyphony | 128 notes |
| Voices | 363 |
| Live Set Sounds | 160 total; 80 preset |
| Performance parts | 3 internal parts with split and layer capability |
| Organ controls | 9 drawbars; 5 organ types; rotary speaker, percussion and vibrato/chorus controls |
| MIDI Master | 4 zones for external MIDI control |
Effects and user interface
| Insertion effects | Drive: 1 system with 5 types; Effect 1 and Effect 2: 36 types each |
|---|---|
| Master effects | 4 delay types; 3 reverb types; 3-band master EQ |
| Display | 128 × 64-dot full-dot LCD |
| Live control | Dedicated category, drawbar, filter, envelope, effect, split and layer controls |
Audio and connectivity
| Line outputs | L/Mono and R, 6.3 mm unbalanced phone jacks |
|---|---|
| A/D inputs | L/Mono and R, 6.3 mm phone jacks, with dedicated effects |
| Headphones | 6.3 mm stereo phone jack |
| Foot-pedal inputs | 2 |
| MIDI | 5-pin MIDI In and Out |
| USB | USB To Host and USB To Device |
| USB audio interface | 44.1 kHz; 2-channel input and 2-channel output |
| Bluetooth | Audio input; availability can vary by market |
Speakers, power and portability
| Amplification | 6 W × 2 |
|---|---|
| Speakers | 2 × 12 cm × 6 cm; switchable on/off |
| Recommended AC adaptor | Yamaha PA-150B or approved equivalent; DC 12 V, 1.5 A |
| Battery operation | 8 AA alkaline or Ni-MH rechargeable batteries; batteries not included |
| Approximate battery life | Up to 4.5 hours with rechargeable Ni-MH batteries or 3 hours with alkaline batteries, depending on use |
| Power consumption | 11 W with PA-150B adaptor |
| Dimensions | 910 × 291 × 109 mm (W × D × H) |
| Weight | 5.6 kg, excluding batteries |
| Compatible soft case | Yamaha SC-DE61, sold separately |
Specifications are based on Yamaha’s published CK61 data. Bluetooth and included accessories can vary by market; please confirm current India-market contents with YMS.
