Yamaha AG06MK2 6-Channel Live Streaming Mixer & USB Audio Interface
Two microphones, two headphone feeds, one USB cable.
- Two combo mic/line inputs, both with +48V phantom power
- CH2 switches to Hi-Z for guitar, with AMP SIM in the DSP
- Two headphone outputs plus a monitor output for powered speakers
- LOOPBACK and MIX MINUS MIC for streaming and remote guests
- 24-bit/192 kHz USB-C audio interface, bus powered and class compliant
Taxes included.
Two Microphones, Two Headphone Feeds, One USB Cable
The AG06MK2 is the AG03MK2 with room for a second person. Two combo inputs, both with +48V phantom power, mean two condenser microphones on the desk — and two independent headphone outputs mean your guest hears the mix without sharing your cans.
Everything else carries over: the one-touch COMP/EQ, SPX reverb and amp simulation run in the hardware at zero latency, LOOPBACK folds your computer's audio into the stream, and the whole thing runs off a single USB-C cable at 24-bit/192 kHz.
At a Glance
What You Get
- Two combo mic/line inputs, both with +48V phantom power. Two condensers, two dynamics, or one of each — this is the smallest AG that handles a two-person podcast properly.
- CH1 also takes a headset mic on 3.5 mm with plug-in power, if you would rather wear a gaming headset than sit behind a boom.
- CH2 switches to Hi-Z for a guitar straight in, with AMP SIM in the DSP — no amplifier or DI box needed.
- Stereo line inputs on both TRS jack and RCA, so a keyboard, a deck or a media player connects without adapters.
- Two headphone outputs plus a monitor output for powered speakers.
- One-touch COMP/EQ and SPX REVERB in the hardware — zero latency, no CPU load, printed to the stream as well as your monitors.
- LOOPBACK and MIX MINUS MIC for streaming and for remote guests who should not hear themselves.
- USB-C, bus powered. 2-in / 2-out, USB Audio Class 2.0, 5 V / 900 mA. 152 × 63 × 201 mm, 0.9 kg. Cubase AI and WaveLab Cast licences included.
Reading the AG Model Names
Yamaha's AG names are straightforward once you know the pattern:
- The number is the channel count — 03, 06, 08.
- MK2 is the second generation, with a USB Type-C connection.
- LSPK means Live Streaming Pack — the mixer bundled with a microphone, headphones and cable.
- AG01 is the exception: a condenser microphone with the AG mixer built into its body.
So this one, the AG06MK2, is the six-channel second-generation mixer — the two-microphone desk of the range.
The Full AG Range at YMS
Every AG model we stock. All USB figures are 24-bit.
| Model | Channels | Mic inputs (+48V) | Hi-Z guitar | USB audio | Sound pads | Weight |
|---|---|---|---|---|---|---|
| AG01 | Mic + line + phone | Built-in condenser | — | 2 in / 2 out, 192 kHz | — | 1.2 kg |
| AG03MK2 | 3 | 1 × combo | Yes (CH1) | 2 in / 2 out, 192 kHz | — | 0.8 kg |
| AG03MK2 LSPK | 3, with mic & headphones | 1 × combo | Yes (CH1) | 2 in / 2 out, 192 kHz | — | 0.8 kg |
| AG06MK2 | 6 | 2 × combo | Yes (CH2) | 2 in / 2 out, 192 kHz | — | 0.9 kg |
| AG08 | 8 | 2 × combo | Yes (CH2) | 8 in / 14 out, 48 kHz | 6 | 2.2 kg |
Watch & Hear It
FAQ
Q. Is the AG06MK2 worth it over the AG03MK2?
If a second person will ever sit down with you, yes — you get a second phantom-powered mic input and a second headphone output. If you always record alone, the AG03MK2 has the same preamps, the same effects and the same loopback for less money.
Q. Can I record the two microphones as separate tracks?
No. The USB interface is 2-in / 2-out, so both mics arrive at your computer as one stereo mix. If you need each voice on its own track to edit later, the AG08 sends 8 channels in over USB.
Q. Do I still need a separate audio interface?
No. The AG06MK2 is a class-compliant USB-C interface at 24-bit/192 kHz and shows up as a recording device in OBS, your DAW or any streaming app.
Q. Will it work with a phone or an iPad?
Yes. There is a 4-pole mini jack for a smartphone, and an iPad connects through Apple's USB-C or Lightning camera adapter.
Q. Which microphones should I pair with it?
Two Yamaha YCM01 condensers is the tidy answer — same voicing on both sides of the table, and both run happily on the AG06MK2's phantom power. Talk to us about boom arms and cables at the same time.
Why Buy from YMS?
YMS For Music is an authorised Yamaha Premium Retailer. Every AG mixer is genuine Yamaha stock with full manufacturer warranty, sold and supported by people who set these up for a living.
Honest advice on which model you actually need, demo units in Bengaluru and Mangaluru, and secure delivery across India. Not sure whether you need two mic inputs? Ask us before you spend.
Specifications
Overview
| Model | Yamaha AG06MK2 |
|---|---|
| Type | 6-channel live streaming mixer and USB audio interface |
| Series | AG Series (2nd generation) |
| Finishes | Black, White |
Channels
| Total Input Channels | 6 |
|---|---|
| Mono MIC/LINE | 2 (combo jack, Mic with +48V phantom power / Line) |
| CH1 Headset Mic | 3.5 mm stereo mini, plug-in power |
| CH2 Guitar Input | Hi-Z switchable |
| Stereo LINE | 2 (phone jack and RCA) |
| Smartphone Input | 4-pole mini jack |
Digital
| USB Audio | USB Audio Class 2.0 compliant, 2 IN / 2 OUT, max 192 kHz, 24-bit |
|---|---|
| Connector | USB Type-C |
| Streaming Out | DRY CH 1-2G / INPUT MIX / LOOPBACK |
| Mix Minus Mic | On / Off |
Processing
| Effects | COMP/EQ, REVERB (SPX Reverb), AMP SIM |
|---|---|
| Latency | Zero-latency hardware processing |
| Control | AG Controller app for Windows, Mac and iOS |
Outputs
| MONITOR OUT | 1 stereo |
|---|---|
| PHONES | 2 (PHONES / HEADSET PHONES) |
| USB Output | 1 |
General
| Dimensions (W x H x D) | 152 x 63 x 201 mm |
|---|---|
| Net Weight | 0.9 kg |
| Power | USB-C bus power, 5 V DC, 900 mA |
| Included | Cubase AI and WaveLab Cast download information |
The USB interface carries a stereo mix, not individual channels - both microphones arrive as one stereo pair. For separate tracks per source, see the AG08. Specifications from Yamaha official product data.
